Assure HD
Heavy-duty security
Our most robust aluminium panel, Assure HD has 25 x 25mm verticals and 40 x 40mm rails to provide maximum toughness and security. With a double top-rail for added strength, Assure HD combines formidable performance with an elegant profile.
The Assure HD panel has been designed to comply with MoE specifications for schools as well as meeting pool regulations for residential use, with raking up to 20 degrees.
-
- Application
- Education & Parks, Civil & Transport, Industrial
-
- Material
- Aluminium
-
- Height
-
Ex-Stock heights at 1500mm & 1800mm H
-
- Width
-
Ex-stock at 2350mm W
Widths up to 2350mm W can be achieved by cutting the width of the panel down
-
- Profiles
-
• 25x25mm aluminium vertical bar
• 100mm gap between verticals
• 40x40mm Horizontal Rails
-
- Colours
-
Ex-stock satin black
Custom colour available on request
-
- Posts
-
• 65x65x2mm in ground aluminium post up to 2500mm L
• 65x65x3mm base plated post up to 2000mm L
-
- Post Centres
-
Up to 2415mm W
-
- Gates
-
Ex-stock pedestrian gates available
• 1500mm H x 1200mm W
• 1800mm H x 1200mm W
-
- Pool Compliant
-
Yes
-
- Balustrade Compliant
-
Yes - contact Urban for design guidance
-
- Raking Panels Available
-
Yes - up to 20 degrees
Double top rail for added strength
Heavy-duty construction
Large anti-climb gap in vertical bars
Exclusively available as raking panel up to 20 degrees
Ideal for:
Designed purposely for schools
Balustrade and retaining wall barriers
Childcare/parks
Cycleways/civil fencing
